Options - Warning

The Warning category settings control the following properties:

• Warning Block - name of the warning block that is inserted on the screen, signaling that the device has a critical warning or simple warning
  • Critical Warning - signals that the device has some problem related to the hydraulic calculation that will prevent it from working properly, for example, slope negative in a tube
  • Simple Warning - Signals that the device has a problem, but this does not prevent it from working.example: Minimum coverage in a tube

Note, these warnings are controlled by the device's rules. You can create rules that signal with some priority (warning or critical)

See also that the block needs to accept a BYBLOCK color that modifies its appearance. If there is no defined block, the program will create it, with the appearance above
