Solids Builder - Visibility State

Visibility State - modifies the visibility status of a property on the SOLIDOS program screens

The Visibility State activity has the following properties:

• Name - name of the activity
  Note that the name here does not need to follow the naming rules
• Properties - Names of properties to have their visibility status changed
• Visibility State - Indicates whether the property is visible. visible (True) or not (False)

This tool will be used. This is useful when there are properties that should be hidden from the user under certain circumstances, for example: assume the user has made a pipe that may or may not have concrete reinforcement. If the tube has one, the user must inform the thickness of this reinforcement.

Note: the property does not cease to exist. She just won't be. visible on SOLIDOS property screens. Something similar occurs when the device should or should not calculate excavation. If you must calculate, then the user has to inform all the parameters necessary for the calculation
